HDMI Extender over single Cat5e/6 cable up to 50M with HDMI loop out, support 1080p ,3D Bi-directional Wide Band IR (38khz-56khz), POC

SX-EX39
$79.99
$79.99

HDMI Extender over single Cat5e/6 cable up to 50M with HDMI loop out, support 1080p ,3D Bi-directional Wide Band IR (38khz-56khz), POC

HDMI Extender over single Cat5e/6 cable up to 50M with HDMI loop out, support 1080p  ,3D Bi-directional Wide Band IR (38khz-56khz), POC

Features

  • Bandwidth upto 18Gbps, Resolution upto 4Kx2K@60Hz, YUV 4:4:4
  • Transmit upto 25m under 4Kx2K@60Hz, YUV 4:4:4, 50m under 1080P@60Hz
  • 1xHDMI in, 1xHDMI out, 1xDC receptacle
  • Connect the included DC to USB AM cable when the power is insufficient
  • HDCP2.2 Compliant
  • CEC Pass through
  • Support 3D
  • No need power supply

Specifications

  • Input 1x HDMI
  • Output 1x HDMI
  • Maximum Range
    4K@60Hz, YUV 4:4:4, 25m (15m to source + 10m to display)
    4K@30Hz, 40m (25m to source + 15m to display)
    1080P@60Hz, 50m (30m to source + 20m to display)
  • Maximum Resolution 4K@60Hz, 4:4:4
  • Data transfer speed rate 18Gbps(Maximum)
  • HDMI Compliance Up to HDMI2.0
  • HDCP Compliance Up to HDCP2.2
  • Operating Temperature Range -5 to +55℃(+23 to +131℉)
  • Operating Humidity Range 5 to 90%RH (No Condensation)
  • Support Video Color Format Deep color 36bit
  • Support Audio Format DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD
  • Power consumption 1watts(Maximum)
  • External Power Source (optional) 5V 150mA on DC receptacle
  • Dimension (L×W×H) 52x45x21mm
  • Net Weight 128g
